Ciircuit:SPDT or DPDT
Rating:5A 125V/250V AC
Contact Resistance:50 milli-Ohm Max(initial)
Insulation Resistance:200Meg-Ohm Min
Operating Force:Single pole:190±50gf
Double pole:250±50gf for square
300±50gf for Rectangular
Toal Travel:2.3±0.5mm
Mechanical Life:1,000,000cycles min.for Momentary.
200,000cycles min.for Alternate
Electrical Life:10,000cycles min
100,000cycles min.with resistive load of 3A@125VAC
Operating Temperature:-25℃~+50℃
